SANYO 6.5inch L5F30369 LCD Panel

    Buy cheap SANYO 6.5inch L5F30369 LCD Panel from wholesalers

    Buy cheap SANYO 6.5inch L5F30369 LCD Panel from wholesalers
    • Buy cheap SANYO 6.5inch L5F30369 LCD Panel from wholesalers

    SANYO 6.5inch L5F30369 LCD Panel

    Ask Lasest Price
    Brand Name : SANYO
    Certification : RoHS Compliant
    Model Number : L5F30369
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    SANYO 6.5inch L5F30369 LCD Panel

    SANYO 6.5inch L5F30369 LCD Panel

    Specification for L5F30369:

    L5F30369 Basic Information

    Panel Model

    L5F30369

    Panel Brand

    SANYO

    Descrition

    a-Si TFT-LCD ,6.5 inch, 800×480

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -30 ~ 85 °C

    Storage Temperature

    -40 ~ 90 °C

    L5F30369 Mechanical Features

    Dot Resolution

    800(RGB)×480 (WVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    144 PPI

    Aspect Ratio

    17:9 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.060×0.163 mm (H×V)

    Pixel Pitch

    0.180×0.163 mm (H×V)

    Weight

    310g

    Surface

    Antiglare

    Active Area

    144×78.24 mm (H×V)

    Outline Dimension

    159.9×93.4 mm (H×V)

    Outline Depth

    14.0/14.0 (Typ./Max.) mm

    Holes & Brackets

    Rear mounting holes

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    L5F30369 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    450 cd/m² (Typ.)

    Contrast Ratio

    250 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Response Time

    20/30 (Typ.)(Tr/Td)

    Viewing Angle

    45/40/35/35 (Typ.)(CR≥20) (L/R/U/D)

    White color Chromaticity

    Wx:0.307; Wy:0.326

    Sunlight Readable

    N

    L5F30369 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    Yes (180°)

    Time Controller (T-CON)

    Need external T-CON

    L5F30369 Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    CCFL

    Lamp Amount

    1 pcs

    Lamp Shape

    U shape

    Lamp Life Time

    15K(Min.) (Hours)

    Lamp Voltage

    755±100V

    Lamp Current

    2.0/7.0/9.0mA (Min./Typ./Max.)

    Lamp Operating Frequency

    30/100KHz (Min./Max.)

    Lamp Startup Voltage

    1900/3230V (Max.)(Ta=+25/0℃)

    Interface Type

    Connector

    Lamp Driver Board

    No

    L5F30369 Signal Interface

    Signal Category

    TTL

    Signal Class

    Parallel RGB (1 ch, 6-bit)

    Input Voltage for Panel

    3.3/5.0/15.0/-30.0 (Typ.)(VSHD/VSHA/VGH/VGL)

    Interface Type

    FPC
