LG Display 7.9inch LP079X01-SMA7 LCD Panel

    Buy cheap LG Display 7.9inch LP079X01-SMA7 LCD Panel from wholesalers

    Buy cheap LG Display 7.9inch LP079X01-SMA7 LCD Panel from wholesalers
    • Buy cheap LG Display 7.9inch LP079X01-SMA7 LCD Panel from wholesalers

    LG Display 7.9inch LP079X01-SMA7 LCD Panel

    Ask Lasest Price
    Brand Name : LG Display
    Certification : RoHS Compliant
    Model Number : LP079X01-SMA7
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    LG Display 7.9inch LP079X01-SMA7 LCD Panel

    LG Display 7.9inch LP079X01-SMA7 LCD Panel

    Specification for LP079X01-SMA7:

    LP079X01-SMA7 Basic Information

    Panel Model

    LP079X01-SMA7

    Panel Brand

    LG Display

    Descrition

    a-Si TFT-LCD ,7.9 inch, 768×1024

    Panel Type

    a-Si TFT-LCD

    Model Alias

    LP079X01 (SM)(A7)

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    Remarks

    for iPad mini

    LP079X01-SMA7 Mechanical Features

    Dot Resolution

    768(RGB)×1024 (XGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    162 PPI

    Aspect Ratio

    3:4 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.052×0.156 mm (H×V)

    Pixel Pitch

    0.156×0.156 mm (H×V)

    Active Area

    119.808×159.744 mm (H×V)

    Bezel Area

    124.32×164.1 mm (H×V)

    Outline Dimension

    129×171.07 mm (H×V)

    Landscape or Portrait

    Portrait type

    Touch Panel

    Without

    LP079X01-SMA7 Optical Features

    Display Mode

    AH-IPS, Normally Black, Transmissive

    Brightness

    425 cd/m² (Typ.)

    Contrast Ratio

    900 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Response Time

    17 (Typ.)(Tr+Td)

    Viewing Angle

    85/85/85/85 (Typ.)(CR≥10) (L/R/U/D)

    Viewing Direction

    Symmetry

    White color Chromaticity

    Wx:0.300; Wy:0.325

    White Variation

    1.18/1.33 (Typ./Max.)(96 points)

    Sunlight Readable

    N

    LP079X01-SMA7 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    Total Power Consumption

    2.22W (Typ.)

    LP079X01-SMA7 Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Amount

    6 strings

    Lamp Shape

    6 strings

    Lamp Life Time

    10K(Min.) (Hours)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    No

    LP079X01-SMA7 Signal Interface

    Signal Category

    MIPI

    Signal Class

    MIPI (4 data lanes)

    Input Voltage for Panel

    3.6V (Typ.)

    Interface Type

    Connector
