    Laibao 2inch S20004B112G48M1T5 LCD Panel

    Ask Lasest Price
    Brand Name : Laibao
    Certification : RoHS Compliant
    Model Number : S20004B112G48M1T5
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    Laibao 2inch S20004B112G48M1T5 LCD Panel

    Laibao 2inch S20004B112G48M1T5 LCD Panel

    Specification for S20004B112G48M1T5:

    S20004B112G48M1T5 Basic Information

    Panel Model

    S20004B112G48M1T5

    Panel Brand

    Laibao

    Descrition

    a-Si TFT-LCD ,2.0 inch, 176×220

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    S20004B112G48M1T5 Mechanical Features

    Dot Resolution

    176(RGB)×220 (QCIF+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    141 PPI

    Aspect Ratio

    4:5 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.060×0.180 mm (H×V)

    Pixel Pitch

    0.180×0.180 mm (H×V)

    Weight

    TBD

    Surface

    Without Polarizer

    Active Area

    31.68×39.6 mm (H×V)

    Outline Dimension

    36.28×47.33 mm (H×V)

    Outline Depth

    1.0 (Typ.) mm

    Landscape or Portrait

    Portrait type

    Touch Panel

    Without

    S20004B112G48M1T5 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    300 : 1 (Typ.) (Transmissive)

    Color Gamut

    58% NTSC (CIE1931)

    Response Time

    25 (Typ.)(Tr+Td)

    Viewing Angle

    45/45/15/35 (Typ.)(CR≥10) (L/R/U/D)

    Transmissivity

    12% (Typ.)(without Polarizer)

    Sunlight Readable

    N

    S20004B112G48M1T5 Electronics Feature

    Driver IC

    Suggest ILI9225, HX8340B, S6D0164, NT39115, SPFD5406B

    S20004B112G48M1T5 Backlight System

    Lamp Type

    No B/L
