    CMO 15.4inch N154C1-P01 LCD Panel

    CMO 15.4inch N154C1-P01 LCD Panel

    Specification for N154C1-P01:

    N154C1-P01 Basic Information

    Panel Model

    N154C1-P01

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,15.4 inch, 1440×900

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    N154C1-P01 Mechanical Features

    Dot Resolution

    1440(RGB)×900 (WXGA+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    110 PPI

    Aspect Ratio

    16:10 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.07675×0.23025 mm (H×V)

    Pixel Pitch

    0.23025×0.23025 mm (H×V)

    Weight

    245/255g (Typ./Max.)

    Surface

    Antiglare, Hard coating (3H)

    Active Area

    331.56×207.225 mm (H×V)

    Outline Dimension

    339.2×214.2 mm (H×V)

    Outline Depth

    1.54 (Typ.) mm

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    N154C1-P01 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    400 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Response Time

    8/23 (Typ.)(Tr/Td)

    Viewing Angle

    65/65/50/60 (Typ.)(CR≥10) (L/R/U/D)

    White color Chromaticity

    Wx:0.317; Wy:0.370

    White Variation

    1.25/1.40 (Typ./Max.)(5 points)

    Transmissivity

    8.9% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    N154C1-P01 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    N154C1-P01 Backlight System

    Lamp Type

    No B/L

    N154C1-P01 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (2 ch, 6-bit)

    Input Voltage for Panel

    3.3V (Typ.)

    Input Current for Panel

    430/500mA (Typ./Max.)

    Interface Type

    Connector

    Signal Interface

    JAE - FI-XB30SRL-HF11, Pitch:1.0 mm, Pin:30 pins
