CMO 2.2inch F02222-02U LCD Panel

    Buy cheap CMO 2.2inch F02222-02U LCD Panel from wholesalers

    Buy cheap CMO 2.2inch F02222-02U LCD Panel from wholesalers
    • Buy cheap CMO 2.2inch F02222-02U LCD Panel from wholesalers

    CMO 2.2inch F02222-02U LCD Panel

    Ask Lasest Price
    Brand Name : CMO
    Certification : RoHS Compliant
    Model Number : F02222-02U
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CMO 2.2inch F02222-02U LCD Panel

    CMO 2.2inch F02222-02U LCD Panel

    Specification for F02222-02U:

    F02222-02U Basic Information

    Panel Model

    F02222-02U

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,2.2 inch, 240×320

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    -20 ~ 70 °C

    Storage Temperature

    -30 ~ 80 °C

    Remarks

    ODF cell

    F02222-02U Mechanical Features

    Dot Resolution

    240(RGB)×320 (QVGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    182 PPI

    Aspect Ratio

    3:4 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.0465×0.1395 mm (H×V)

    Pixel Pitch

    0.1395×0.1395 mm (H×V)

    Surface

    Without Polarizer

    Active Area

    33.48×44.64 mm (H×V)

    Outline Dimension

    51.62×36.88 mm (H×V)

    Outline Depth

    0.6 (Typ.) mm

    Landscape or Portrait

    Portrait type

    Touch Panel

    Without

    F02222-02U Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    300 : 1 (Typ.) (Transmissive)

    Response Time

    10/20 (Typ.)(Tr/Td)

    Viewing Angle

    45/45/35/15 (Typ.)(CR≥10) (L/R/U/D)

    Transmissivity

    5.6% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    F02222-02U Electronics Feature

    Driver IC

    COG Suggest HX8347D

    F02222-02U Backlight System

    Lamp Type

    No B/L
