CMO 21.6inch V216B1-P04 LCD Panel

    Buy cheap CMO 21.6inch V216B1-P04 LCD Panel from wholesalers

    Buy cheap CMO 21.6inch V216B1-P04 LCD Panel from wholesalers
    • Buy cheap CMO 21.6inch V216B1-P04 LCD Panel from wholesalers

    CMO 21.6inch V216B1-P04 LCD Panel

    Ask Lasest Price
    Brand Name : CMO
    Certification : RoHS Compliant
    Model Number : V216B1-P04
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CMO 21.6inch V216B1-P04 LCD Panel

    CMO 21.6inch V216B1-P04 LCD Panel

    Specification for V216B1-P04:

    V216B1-P04 Basic Information

    Panel Model

    V216B1-P04

    Panel Brand

    CMO

    Descrition

    a-Si TFT-LCD ,21.6 inch, 1366×768

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    V216B1-P04 Mechanical Features

    Dot Resolution

    1366(RGB)×768 (WXGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    72 PPI

    Aspect Ratio

    16:9 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.1165×0.3495 mm (H×V)

    Pixel Pitch

    0.3495×0.3495 mm (H×V)

    Weight

    606g (Typ.)

    Surface

    Antiglare, Hard coating (3H)

    Active Area

    477.417×268.416 mm (H×V)

    Outline Dimension

    488.917×279.916 mm (H×V)

    Outline Depth

    2.0 (Typ.) mm

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    V216B1-P04 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    800 : 1 (Typ.) (Transmissive)

    Display Color

    16.7M (6-bit + Hi-FRC)

    Color Gamut

    72% NTSC (CIE1931)

    Response Time

    1.3/3.7 (Typ.)(Tr/Td)

    Viewing Angle

    85/85/80/80 (Typ.)(CR≥10) (L/R/U/D)

    Transmissivity

    7.25% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    V216B1-P04 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    V216B1-P04 Backlight System

    Lamp Type

    No B/L

    V216B1-P04 Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (1 ch, 8-bit)

    Input Voltage for Panel

    5.0V (Typ.)

    Input Current for Panel

    0.85/0.95A (Typ./Max.)

    Interface Type

    Connector

    Signal Interface

    JAE - FI-X30SSL-HF, Pitch:1.0 mm, Pin:30 pins
