TIANMA 9.7inch LP097QX1-SPC4 LCD Panel

    Buy cheap TIANMA 9.7inch LP097QX1-SPC4 LCD Panel from wholesalers

    Buy cheap TIANMA 9.7inch LP097QX1-SPC4 LCD Panel from wholesalers
    • Buy cheap TIANMA 9.7inch LP097QX1-SPC4 LCD Panel from wholesalers

    TIANMA 9.7inch LP097QX1-SPC4 LCD Panel

    Ask Lasest Price
    Brand Name : TIANMA
    Certification : RoHS Compliant
    Model Number : LP097QX1-SPC4
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union ,Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    TIANMA 9.7inch LP097QX1-SPC4 LCD Panel

    TIANMA 9.7inch LP097QX1-SPC4 LCD Panel

    Specification for LP097QX1-SPC4:

    LP097QX1-SPC4 Basic Information

    Panel Model

    LP097QX1-SPC4

    Panel Brand

    LG Display

    Descrition

    a-Si TFT-LCD ,9.7 inch, 2048×1536

    Panel Type

    a-Si TFT-LCD

    Model Alias

    LP097QX1 (SP)(C4)

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -20 ~ 60 °C

    Remarks

    for iPad 3

    LP097QX1-SPC4 Mechanical Features

    Dot Resolution

    2048(RGB)×1536 (QXGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    264 PPI

    Aspect Ratio

    4:3 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.032×0.096 mm (H×V)

    Pixel Pitch

    0.096×0.096 mm (H×V)

    Active Area

    196.608×147.456 mm (H×V)

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    LP097QX1-SPC4 Optical Features

    Display Mode

    IPS, Normally Black, Transmissive

    Brightness

    440 cd/m² (Typ.)

    Display Color

    16.7M (8-bit)

    Viewing Direction

    Symmetry

    Sunlight Readable

    N

    LP097QX1-SPC4 Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    LP097QX1-SPC4 Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    LP097QX1-SPC4 Signal Interface

    Signal Category

    eDP

    Signal Class

    eDP (4 Lanes)

    Interface Type

    FPC
