CPT 9.8inch CLAA098EP01XG LCD Panel

    Buy cheap CPT 9.8inch CLAA098EP01XG LCD Panel from wholesalers

    Buy cheap CPT 9.8inch CLAA098EP01XG LCD Panel from wholesalers
    • Buy cheap CPT 9.8inch CLAA098EP01XG LCD Panel from wholesalers

    CPT 9.8inch CLAA098EP01XG LCD Panel

    Ask Lasest Price
    Brand Name : CPT
    Certification : RoHS Compliant
    Model Number : CLAA098EP01XG
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    CPT 9.8inch CLAA098EP01XG LCD Panel

    CPT 9.8inch CLAA098EP01XG LCD Panel

    Specification for CLAA098EP01XG:

    CLAA098EP01XG Basic Information

    Panel Model

    CLAA098EP01XG

    Panel Brand

    CPT

    Descrition

    a-Si TFT-LCD ,9.8 inch, 1280×960

    Panel Type

    a-Si TFT-LCD

    Operating Temperature

    0 ~ 50 °C

    Storage Temperature

    -25 ~ 65 °C

    CLAA098EP01XG Mechanical Features

    Dot Resolution

    1280(RGB)×960 (Quad-VGA)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    162 PPI

    Aspect Ratio

    4:3 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.052×0.156 mm (H×V)

    Pixel Pitch

    0.156×0.156 mm (H×V)

    Active Area

    199.68×149.76 mm (H×V)

    Landscape or Portrait

    Landscape type

    Touch Panel

    Without

    CLAA098EP01XG Optical Features

    Display Mode

    HFFS, Normally Black, Transmissive

    Brightness

    400 cd/m² (Typ.)

    Contrast Ratio

    900 : 1 (Typ.) (Transmissive)

    Display Color

    16.7M (6-bit + Hi-FRC)

    Color Gamut

    50% NTSC (CIE1931)

    Response Time

    30 (Typ.)(Tr+Td)

    Viewing Angle

    80/80/80/80 (Min.)(CR≥10) (L/R/U/D)

    Viewing Direction

    Symmetry

    White color Chromaticity

    Wx:0.314; Wy:0.335

    Sunlight Readable

    N

    CLAA098EP01XG Electronics Feature

    Vertical Frequency

    60Hz

    Reverse Scan

    No

    CLAA098EP01XG Backlight System

    Lamp Position

    Edge light type

    Lamp Type

    WLED

    Lamp Life Time

    15K(Min.) (Hours)

    Interface Type

    Included in panel signal interface

    Lamp Driver Board

    Embedded (LED Driver)

    CLAA098EP01XG Signal Interface

    Signal Category

    LVDS

    Signal Class

    LVDS (1 ch, 8-bit) + SPI

    Interface Type

    Connector
