AUO 2inch H200HN05 V3 LCD Panel

    Buy cheap AUO 2inch H200HN05 V3 LCD Panel from wholesalers

    Buy cheap AUO 2inch H200HN05 V3 LCD Panel from wholesalers
    • Buy cheap AUO 2inch H200HN05 V3 LCD Panel from wholesalers

    AUO 2inch H200HN05 V3 LCD Panel

    Ask Lasest Price
    Brand Name : AUO
    Certification : RoHS Compliant
    Model Number : H200HN05 V3
    Price : Pls Contact sales team
    Delivery Time : stock
    Payment Terms : T/T , Paypal, Western Union Escrow etc.
    Supply Ability : 1000
    • Product Details
    • Company Profile

    AUO 2inch H200HN05 V3 LCD Panel

    AUO 2inch H200HN05 V3 LCD Panel

    Specification for H200HN05 V3:

    H200HN05 V3 Basic Information

    Panel Model

    H200HN05 V3

    Panel Brand

    AUO

    Descrition

    a-Si TFT-LCD ,2.0 inch, 176×220

    Panel Type

    a-Si TFT-LCD

    Model Alias

    H200HN05 V.3

    Operating Temperature

    -20 ~ 60 °C

    Storage Temperature

    -55 ~ 110 °C

    H200HN05 V3 Mechanical Features

    Dot Resolution

    176(RGB)×220 (QCIF+)

    Pixel Configuration

    RGB Vertical Stripe

    Pixel Density

    141 PPI

    Aspect Ratio

    4:5 (H:V)

    Form Factor

    Flat Rectangle Display

    Dot Pitch

    0.060×0.180 mm (H×V)

    Pixel Pitch

    0.180×0.180 mm (H×V)

    Weight

    3.5±0.3g

    Surface

    Without Polarizer

    Active Area

    31.68×39.6 mm (H×V)

    Outline Dimension

    35.08×47.1 mm (H×V)

    Outline Depth

    1.0 (Typ.) mm

    Landscape or Portrait

    Portrait type

    Touch Panel

    Without

    H200HN05 V3 Optical Features

    Display Mode

    TN, Normally White, Transmissive

    Brightness

    0 cd/m²

    Contrast Ratio

    200 : 1 (Typ.) (Transmissive)

    Display Color

    262K (6-bit)

    Response Time

    10/20 (Typ.)(Tr/Td)

    Viewing Angle

    40/40/60/15 (Min.)(CR≥10) (L/R/U/D)

    Viewing Direction

    12 o'clock

    Transmissivity

    6.5% (Typ.)(with Polarizer)

    Sunlight Readable

    N

    H200HN05 V3 Electronics Feature

    Driver IC

    Suggest S6D0164

    H200HN05 V3 Backlight System

    Lamp Type

    No B/L

    H200HN05 V3 Signal Interface

    Signal Category

    CPU/SPI

    Signal Class

    CPU/SPI

    Input Voltage for Panel

    1.8/2.8V (Typ.)(VDD/VCI)
