LCD Panel Types HSD121PHW1-B00 HannStar 12.1 inch with 250 cd/m² (Typ.)

Ask Lasest Price
Brand Name :	HannStar
Certification :	ROHS COMPLIANT
Model Number :	HSD121PHW1-B00
Price :	Contact for Sample
Delivery Time :	Within 3days
Payment Terms :	T/T in advance, Paypal, Western Union
Supply Ability :	14123

Add to Cart

Product Details
Company Profile

LCD Panel Types HSD121PHW1-B00 HannStar 12.1 inch with 250 cd/m² (Typ.)

Optical Features

Display Mode :	TN, Normally White, Transmissive
Brightness :	250 cd/m² (Typ.)
Contrast Ratio :	500 : 1 (Typ.) (Transmissive)
Display Color :	262K (6-bit)
Color Gamut :	50% NTSC (CIE1931)
Response Time :	3/9 (Typ.)(Tr/Td)
Viewing Angle :	80/80/70/80 (Typ.)(CR≥10) (L/R/U/D)
White color Chromaticity :	Wx:0.313; Wy:0.329
White Variation :	1.25/1.43 (Max.)(5/13 points)

Basic Information

Panel Brand :
Panel Model :	HSD121PHW1-B00
Panel Type :	a-Si TFT-LCD , Panel
Application :
Operating Temperature :	0 ~ 50 °C
Storage Temperature :	-20 ~ 60 °C

Mechanical Features

Panel Size :	12.1 inch
Dot Resolution :	1366(RGB)×768 (WXGA)
Pixel Configuration :	RGB Vertical Stripe
Pixel Density :	129 PPI
Aspect Ratio :	16:9 (H:V)
Form Factor :	Flat Rectangle Display
Dot Pitch :	0.0654×0.1962 mm (H×V)
Pixel Pitch :	0.1962×0.1962 mm (H×V)
Weight :	250/265g (Typ./Max.)
Surface :	Antiglare, Hard coating (3H)
Active Area :	268.01×150.68 mm (H×V)
Bezel Area :	271.01×153.48 mm (H×V)
Outline Dimension :	279×167.2 mm (H×V)
Outline Depth :	5.1 (Max.) mm
Shape Style :	Wedge (PCBA Bent, Depth ≥5.2mm)
Holes & Brackets :	Side mounting holes (4-M2) on left, right bezel
Landscape or Portrait :	Landscape type
Touch Panel :	Without

Electronics Feature

Vertical Frequency :	60Hz
Reverse Scan :	No
