    LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.)

    Ask Lasest Price
    Brand Name : SHARP
    Certification : ROHS COMPLIANT
    Model Number : LQ121S1LG88
    Price : Contact for Sample
    Delivery Time : Within 3days
    Payment Terms : T/T in advance, Paypal, Western Union
    Supply Ability : 1234
    • Product Details
    • Company Profile

    LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.)

    LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.)

    Basic Information

    Panel Brand :LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.)
    Panel Model :LQ121S1LG88 LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.) 1 Compatible model
    Panel Type :a-Si TFT-LCD , Panel
    Application :

    LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.)LCD Panel Types SHARP LQ121S1LG88 12.1 inch with 450 cd/m² (Typ.)

    Operating Temperature :-15 ~ 70 °C
    Storage Temperature :-30 ~ 80 °C

    Mechanical Features

    Panel Size :12.1 inch
    Dot Resolution :800(RGB)×600 (SVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :82 PPI
    Aspect Ratio :4:3 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.1025×0.3075 mm (H×V)
    Pixel Pitch :0.3075×0.3075 mm (H×V)
    Weight :750g (Max.)
    Surface :Antiglare, Hard coating (3H)
    Active Area :246×184.5 mm (H×V)
    Bezel Area :249.0×187.5 mm (H×V)
    Outline Dimension :276×209 mm (H×V)
    Outline Depth :9.6 (Max.) mm
    Holes & Brackets :Face mounting holes (2-Φ3.4, 2-R1.7) on left, right bezel
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    Optical Features

    Display Mode :TN, Normally White, Transmissive
    Brightness :450 cd/m² (Typ.)
    Contrast Ratio :800 : 1 (Typ.) (Transmissive)
    Display Color :262K (6-bit)
    Color Gamut :53% NTSC (CIE1931)
    Response Time :30 (Typ.)(Tr+Td)
    Viewing Angle :80/80/60/80 (Typ.)(CR≥10) (L/R/U/D)
    Viewing Direction :6 o'clock
    White color Chromaticity :Wx:0.300; Wy:0.315
    White Variation :1.33 (Max.)(5 points)

    Electronics Feature

    Vertical Frequency :60Hz
    Reverse Scan :Yes (180°)
