LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m²

    Buy cheap LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m² from wholesalers

    Buy cheap LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m² from wholesalers
    • Buy cheap LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m² from wholesalers

    LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m²

    Ask Lasest Price
    Brand Name : TOSHIBA
    Certification : ROHS COMPLIANT
    Model Number : LTA104D182F
    Price : Contact for Sample
    Delivery Time : Within 3days
    Payment Terms : T/T in advance, Paypal, Western Union
    Supply Ability : 36000
    • Product Details
    • Company Profile

    LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m²

    LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m²

    Basic Information

    Panel Brand :LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m²
    Panel Model :LTA104D182F
    Panel Type :LTPS TFT-LCD , Panel
    Application :

    LCD Panel Types TOSHIBA LTA104D182F 10.4 inch 262K (6-bit) with 400 cd/m²

    Operating Temperature :-20 ~ 70 °C
    Storage Temperature :-30 ~ 80 °C

    Mechanical Features

    Panel Size :10.4 inch
    Dot Resolution :800(RGB)×600 (SVGA)
    Pixel Configuration :RGB Vertical Stripe
    Pixel Density :96 PPI
    Aspect Ratio :4:3 (H:V)
    Form Factor :Flat Rectangle Display
    Dot Pitch :0.088×0.264 mm (H×V)
    Pixel Pitch :0.264×0.264 mm (H×V)
    Weight :580g (Typ.)
    Active Area :211.2×158.4 mm (H×V)
    Bezel Area :214.6×162.4 mm (H×V)
    Outline Dimension :242×178.5 mm (H×V)
    Outline Depth :13.2 (Typ.) mm
    Holes & Brackets :Face mounting holes
    Landscape or Portrait :Landscape type
    Touch Panel :Without

    Optical Features

    Display Mode :TN, Normally White, Transmissive
    Brightness :400 cd/m² (Typ.)
    Contrast Ratio :450 : 1 (Typ.) (Transmissive)
    Display Color :262K (6-bit)
    Response Time :8/17 (Typ.)(Tr/Td)
    Viewing Angle :60/60/50/50 (Typ.)(CR≥10) (L/R/U/D)

    Pls check the below LCD panel.If you need any other LCD display.pls contact with us:

    HSD023F3N1-A01HannStar2.3"320×240
    HSD018F1N9-A01HannStar1.8"128×160
    LC650EGY-SHM1LG Display65"3840×2160
    LC650DUY-SGM1LG Display65"1920×1080
    BS053HDG-N50-6200BOE5.3"720×1280
    ST5461D02-2CSOT55"3840×2160
    H520DAN01.0AUO5.2"1080×1920
    CLAN070NJ01 CWCPT7.0"1024×600
    HV550QUB-B10BOE55"3840×2160
    TL050JGXP01Tianma5.0"720×1280
    LH499WX1-SH01LG Display5.0"720×1280
    HSD045F8W1-C01HannStar4.5"480×854
    H160QVN01.0AUO1.6"320×320
    LSN133DL01-A02Samsung13.3"2560×1600
    LM195WD1-TJBALG Display19.5"1600×900
    LSC480HN08Samsung48"1920×1080
    TM050JYHP05Tianma5.0"720×1280
    F050A13-601Innolux5.0"720×1280
    BF039WVQ-100BOE3.9"480×800
    ST3151A04-8CSOT31.5"1366×768
    TM060XYSP01Tianma6.0"540×960
    LH430WV6-SH01LG Display4.3"480×800
    LH500WX2-SH05LG Display5.0"720×1280
    HV480FH2-600BOE48"1920×1080
    LC320HU1APANDA31.5"2560×1440
    P097ZCA-1Z2Innolux9.7"1024×768
    H466TAN03.0AUO4.6"720×1280
    LSC550HN01Samsung55"1920×1080
    LQ079L1SX06SHARP7.9"1536×2048
    LQ079L1SX04SHARP7.9"1536×2048
    LQ133M1JW08SHARP13.3"1920×1080
    LSL080AL02-201Samsung8.0"800×1280

    Competitive Advantage:
    Warranty :180 days !
    Free shipping: Order over $1000 win a free shipment fee
    (goods weight below 3Kg) ,during 20130901-20130930 .


    Why buy from us >>> Fast / Safely / Conveniently
    • Mega Source is a Stock keeper and trade company of Electronic components .Our branches office include China, Hong Kong, Sigapore , Canada . Offer business, service, resourcing and information for our global member.
    • Goods are ensured the highest quality possible and are delivered to our customers all over the world with speed and precision.


    How to buy >>>
    • Contact us by email & sent your inquire with your Transport destination .
    • Online chat, the commissioner would be responded ASAP.


    Service >>>
    • Forwarder Shipment to world-wide, DHL ,TNT ,UPS,FEDEX etc. buyer don`t need to worry about shipping problem
    • We will try to respond as quickly as possible. But due to time zone difference, please allow up to 24 hours to get your mail replied. The products were tested by some devices or software, we ensure that there is no quality problems.
    • We are committed to providing fast, convenient and safe transportation service to global buyer.

    LCD Panel Types AUO G043FW01 V0 4.3 inch New in stock with 450 cd/mƒÆ’†™ƒ¢¢š¬…¡ƒÆ’¢‚¬Å¡ƒš‚² (Typ.)
